Notice before order
1) Parts included: LED module, signal cable between modules, power cable between module and power supply.
2) Buy modules of same batch: to avoid brightness&color difference on one single screen, you must buy modules of the same batch. That is, you must buy the modules for one single screen by one order from us.
3) Tariff:our price does not include any tariffs or duties at the destination, you should do import customs clearance and pay all tariff or duties locally.
P6 Outdoor SMD3535 LED Module 192x192mm Features:
1) Small pixel pitch 6mm for SMD outdoor LED screen, good solution for outdoor rental LED screen and outdoor fixed installation LED display.
2) 6mm is one of the pixel pitches of usual Outdoor LED screens. Therefore, it is a very good solution for rental LED screen for both outdoor and indoor use.
3) The module size is 192x192mm, which is of our universal module series. It is convenient for clients to promote it. What is more,users can update their old LED screen made of our universal modules easily.
4) Reasonable PCB design with good heat radiation and achieve long life span.
P6 Outdoor SMD3535 LED Module 192x192mm Parameters:
|
Item |
Specification |
|
LED type |
SMD3535 |
|
Pixel pitch |
6mm |
|
Pixel configuration |
1R1G1B |
|
Module Size |
192x192mm |
|
Module resolution |
32x32pixels |
|
Density |
27,778 pixels/ ㎡ |
|
Driving Mode |
1/8 duty |
|
Brightness |
≥5500CD/ ㎡ |
|
Viewing angle |
H:120°, V:120° |
|
Best viewing distance |
6m—60m |
|
Working voltage |
5V |
|
Power consumption |
22W |
|
Module weight |
0.51KG |
|
>Protection grade |
Front: IP65 |
|
Working Temperature |
-20 ～60℃ |
|
Package Measurement |
49cmx47cmx45cm |
|
Gross Weight |
22kg |
