G-Energy N200V5-A 5V 40A 200W LED Power Supply

Original price was: $9.00.Current price is: $6.80.

G-Energy N200V5-A LED display power supply, rated 5 V DC, 40 A and up to 200 W. Requires 200–240 V AC input. Check the model suffix and mounting fit before ordering.

SKU: G-Energy-N200V5-A Category: Brand:

Availability: 3296 in stock

G-Energy N200V5-A LED display power supply

The G-Energy N200V5-A is a 5 V DC power supply for LED cabinets. It is rated at up to 40 A and 200 W. The specified input is 200–240 V AC, so check the cabinet’s supply voltage before ordering.

For a replacement, match the full model suffix and the mounting dimensions. The V1.1 drawing lists 190 × 84 × 30 mm. Use the notes below to check which edition of the specification applies to the unit you are buying.

N200V5-A Specifications

The table shows the original listing values. The linked V1.1 datasheet gives different values for storage temperature, power factor, leakage current and input-to-output insulation. Confirm the unit’s revision before using these values for cabinet design.

G-Energy N200V5-A listed parameters
ItemSpecification
DC output5V / 40A
Max. power200W
AC input200–240Vac
AC frequency47–63Hz
Power factorOriginal listing 0.50 at 230 V AC. V1.1 states at least 0.52 at rated input and full load.
Leakage currentOriginal listing 0.30 mA at 230 V AC. V1.1 states below 1.0 mA at 220 V AC.
Operating temp.−30 to +60°C
Storage temp.Original listing −40 to +100 °C. V1.1 lists a storage environment of −40 to +80 °C.
Input to outputOriginal listing 3.0 kV AC. V1.1 specifies a 2.0 kV AC dielectric test at 10 mA for 1 minute.
Insulation to FG1.5KVac / 0.5KVac
ProtectionUndervoltage, overload and short circuit
Standards citedGB4943 and EN60950 are cited in the original listing. Check the datasheet and unit markings for applicable safety information.
CoolingV1.1 describes natural cooling. Check its mounting and heat-dissipation requirements for the cabinet.
Size190 × 84 × 30 mm in the V1.1 drawing

Check Before Ordering

Match the full N200V5-A model suffix, the required DC output and the cabinet mounting arrangement. A 110V supply is outside the listed input range. The price and purchasing controls at the top of this page provide the current offer; contact us if you need the supplied revision confirmed.

Product Photos

G-Energy N200V5-A power supply product view
G-Energy N200V5-A  5V40A 200W LED Display Power Supply
G-Energy N200V5-A  5V40A 200W LED Display Power Supply

Specification Download

G-Energy N200V5-A Power  Specification

Frequently Asked Questions

What are the N200V5-A output ratings?

This product is listed as 5V 40A with a maximum output power of 200W. Check the operating conditions and load requirements for the supplied revision.

Can the N200V5-A operate on 110V AC?

110V AC is outside the listed 200–240Vac input range. Select a power supply with an input specification that matches your installation.

Where can I see the N200V5-A price and buy it?

The current price and purchasing controls are shown at the top of this product page. Confirm the full model and cabinet requirements before ordering.

Are product photos and a specification PDF available?

Yes. The original three product photos are shown above, followed by the specification download. Compare the model label and mounting details when checking a replacement.

Why do some PDF values differ from the product table?

The linked PDF is version V1.1, dated 2012/3/31, and several entries differ from this listing. The table retains the listed sales-version values; confirm the document that applies to the actual supplied unit.

Will I be charged with customs and taxes?

The prices displayed on our site are tax-free in US Dollars, which means you may be liable to pay for duties and taxes once you receive your order. Import taxes, duties and related customs fees may be charged once your order arrives to its final destination, which are determined by your local customs office. Payment of these charges and taxes are your responsibility and will not be covered by us. We are not responsible for delays caused by the customs department in your country. For further details of charges, please contact your local customs office.

Weight0.6 kg
