Plastic Mounting Bracket for LED Receiving Cards
The LED-RCB general plastic bracket is a lightweight carrier frame for mounting an LED receiving card in an LED display assembly. Also described as a receiving card underframe or holder, it is intended for DIY screen builds and receiving-card mounting applications.
Choose this accessory by its physical fit with your card and cabinet. Brand name alone does not establish compatibility: check the board dimensions, mounting-hole positions and space around the connectors before ordering.
Product Details
| Item | Details |
|---|---|
| Product type | LED receiving card mounting bracket / carrier frame |
| SKU | LED-RCB |
| Material | Plastic |
| Construction | Lightweight frame |
| Intended use | Receiving-card mounting in DIY LED display assemblies |
| Compatibility check | Confirm the exact receiving card model, board size, mounting-hole layout and cabinet clearance. |
Receiving Card Compatibility
The product listing identifies Linsn, NovaStar, Colorlight, Xixun and Huidu as intended receiving-card brands. This is a general mounting accessory, not a guarantee that every card from these brands will fit. Cards within the same brand may have different board layouts and mounting requirements.
Bracket dimensions, hole spacing and a numerical temperature rating are not specified here. If these details affect your installation, contact us with your receiving card model, measurements and mounting-area photos to confirm suitability.
What to Check Before Installation
- Match the mounting points: compare the card’s fixing holes and board outline with the bracket before fastening.
- Check cabinet space: allow room for the card, cable plugs and access during maintenance.
- Confirm the fixing hardware: verify the required fastener sizes and supplied items before ordering.
- Install with power disconnected: follow the receiving card and cabinet installation instructions, and avoid placing stress on the circuit board or connectors.
For a complete build, browse our LED receiving cards and LED control card accessories.
Frequently Asked Questions
What is this LED receiving card bracket used for?
It is a plastic carrier frame used to mount a receiving card as part of an LED display assembly. It is a mechanical mounting accessory.
Will it fit my NovaStar, Linsn or Colorlight receiving card?
These brands are identified in the product listing, but fit must be checked for the exact model. Compare the board dimensions, mounting holes and connector clearance before ordering. The same check applies to Xixun and Huidu cards.
Are bracket dimensions and mounting-hole spacing available?
Those measurements are not specified on this page. Contact us with the receiving card model and your installation measurements to confirm the bracket fit before purchase.
Are screws or a receiving card included?
The listed product is the plastic bracket. A receiving card and fixing hardware are not confirmed as included; please verify the supplied items before ordering.
