NovaStar CVT320 Fiber Converter for LED Displays
The NovaStar CVT320 converts between electrical and optical signals to carry LED display data over single-mode fiber. It connects the sending side of an LED control system to the display through a Gigabit Ethernet port and a dual-core LC optical port. Driver-free operation makes it ready to use after connection.
Key Specifications
| Model | NovaStar CVT320 |
|---|---|
| Ethernet connection | 1 × Gigabit Ethernet port |
| Optical connection | 1 × single-mode, twin-core LC port; factory-installed optical module |
| Optical rate / wavelength | 1.25 Gb/s / 1310 nm |
| Power input | AC 100–240 V, 50/60 Hz |
| Setup | No driver installation required |
Transmission Distance: 15 km or 20 km?
This store’s earlier listing specified 15 km. NovaStar’s CVT320 specifications V2.3.4 list an optical transmission distance of up to 20 km. Before planning a long fiber run, confirm the supplied optical module, hardware version and fiber link requirements with us. The newer specification should not be treated as a guaranteed 20 km range for every existing unit.
Plan Your LED Display Fiber Connection
Use the CVT320 when the sending equipment and LED display need a long-distance optical connection. The connection layout depends on whether your sending card has a compatible optical output. Check the sender model, receiving equipment, LC connector type and single-mode fiber route before ordering.
For help choosing the connection layout, contact us with your controller model, planned cable distance and existing fiber details. You can also browse LED control card accessories.
Frequently Asked Questions
Does the CVT320 use single-mode or multimode fiber?
The CVT320 uses single-mode, dual-core optical fiber with LC connectors. Match the cable and both optical endpoints to this specification.
Is software needed to use the converter?
No driver is required for the CVT320 itself. The connected LED control equipment still needs the correct system configuration.
Can I choose it as a general-purpose Ethernet converter?
Its documented application is optical and electrical signal conversion in LED display control systems. Confirm compatibility for your intended equipment rather than assuming every Ethernet or optical device will work with it.
Product Images and Documentation
Download Specification
Novastar CVT320 Single-mode optic fiber converter Specification
NovaStar CVT320 official specifications V2.3.4 (PDF) — reference for the updated optical distance and interface specifications.
