NovaStar MX30 LED Video Wall Control Server Overview
The NovaStar MX30 is an all-in-one LED video wall control server in the COEX control system. It combines video processing and LED display control in a single device, helping simplify system design for rental staging, live events, broadcast studios, control rooms and other professional LED video wall applications.
For buyers comparing an MX30 processor, controller or video wall server, the key specification is its 6.5-million-pixel loading capacity. The unit provides 10 × Gigabit Ethernet outputs and 2 × 10G optical outputs, while the VMP visual management platform supports configuration, monitoring and day-to-day control.
NovaStar MX30 Key Specifications
| Specification | NovaStar MX30 details |
|---|---|
| Maximum loading capacity | 6.5 million pixels |
| Video inputs | 1 × HDMI 2.0 with loop output; 1 × HDMI 1.4 with loop output; 1 × DP 1.1; 2 × 3G-SDI with loop output |
| Input bit depth | 10-bit and 8-bit video source input |
| LED data outputs | 10 × Gigabit Ethernet ports |
| Optical outputs | 2 × 10G optical ports |
| Audio output | 1 × SPDIF digital audio interface |
| Synchronization | 1 × Genlock input with loop output |
| Control interfaces | 2 × Ethernet control ports and 1 × AUX interface |
| Management software | NovaStar VMP visual management platform |
Video Processing and Display Control Features
Three independent layers
The MX30 can display up to three independent layers. Layer size and position can be adjusted, and the Z-order can be changed to place content in the required foreground or background position.
Flexible screen scaling
Four scaling modes are available, including custom scaling and pixel-to-pixel display. This helps operators match source content to standard canvases, wide LED walls and other custom resolutions.
HDR and precise color adjustment
HDR is supported for content that requires a wider visual range. The controller also provides adjustment for 12 standard colors derived from black, white and the RGB primary colors, including hue, saturation and brightness controls.
Full-grayscale calibration
When used with the NovaStar high-precision calibration system and C3200 scientific-grade camera, the system can generate correction coefficients for individual grayscale levels. This improves grayscale uniformity and overall LED display image quality.
Low-latency operation
The MX30 supports low-latency processing without reducing loading capacity. In independent master mode, controller-side latency can be reduced to 0 frames (less than 1 ms). In video controller mode, controller-side latency is 1 frame. An additional 0 to 2 frames of delay can also be configured when synchronization requires it.
Irregular screen mapping
Special-shaped LED screens are not restricted to a rectangular frame. Blank canvas areas are not counted toward loading capacity; Ethernet-port loading is calculated from the combined pixels of the connected LED cabinets.
Frame-rate adaptation and monitoring
The controller adapts to multiple input frame rates, including fractional rates. Users can define a frame rate and fine-tune it in 0.01 Hz steps. Device and display status monitoring provides fault and alarm information for faster troubleshooting.
Two Working Modes
- Independent master mode: designed for applications where minimizing latency is the priority.
- Video controller mode: enables video processing functions such as multi-layer composition and scaling.
The appropriate mode depends on whether the project prioritizes the lowest possible latency or integrated image composition. Contact our sales team with the LED wall resolution, cabinet layout, input sources and redundancy requirements for configuration guidance.
Typical Applications
- Live event and rental LED video walls
- Broadcast studios and production environments
- Conference rooms, auditoriums and command centers
- Large-format commercial LED displays
- Stadium and venue video wall control systems
- Irregular or custom-shaped LED screen installations
NovaStar MX30 Product Images
Downloads
NovaStar MX30 FAQ
What is the NovaStar MX30?
The NovaStar MX30 is an all-in-one LED video wall control server that integrates video processing and LED display control. It belongs to the NovaStar COEX control system and is managed through the VMP platform.
How many pixels can the NovaStar MX30 control?
The MX30 has a maximum loading capacity of 6.5 million pixels through 10 × Gigabit Ethernet output ports.
Which video inputs does the MX30 support?
It supports HDMI 2.0, HDMI 1.4, DisplayPort 1.1 and two 3G-SDI inputs. HDMI and 3G-SDI connections include loop outputs for signal distribution.
Does the MX30 provide optical fiber outputs?
Yes. It provides two 10G optical output ports for fiber-based LED display signal transmission.
Can the MX30 control a non-rectangular LED screen?
Yes. Its mapping workflow supports special-shaped screens without counting blank canvas areas as loaded pixels.
Does the NovaStar MX30 support Genlock and low latency?
Yes. It has a Genlock input with loop output. Independent master mode can provide 0-frame controller-side delay (less than 1 ms), while video controller mode uses 1 frame of controller-side delay.
