SheenColor H1 for Bus and Taxi LED Signs
The SheenColor H1 asynchronous control system stores programs for playback without a continuously connected computer. The described system uses one main board with receiving boards and supports video, image and text content.
Stored Programs for Bar-Shaped Displays
The H1 description identifies bar displays and screens with unusually long aspect ratios as intended applications. Built-in eMMC storage holds programs locally. Temperature collection and automatic brightness adjustment are also listed; confirm the required sensing accessories for the supplied configuration.
SheenColor H1 Specifications
| Parameter | Specification |
|---|---|
| Control mode | Asynchronous full-color LED control |
| System arrangement | One main board with receiving boards |
| Storage | 32 GB eMMC |
| Grayscale | 65,536 levels |
| Program content | Video, images and text |
| Module options on this page | H1 with 3G module or H1 with 4G module |
| Additional functions listed | Temperature collection and automatic brightness adjustment |
Choose the Correct Module Version
Select the required 3G or 4G option and verify its compatibility with the intended mobile network. Confirm the receiving-board arrangement, total screen resolution and module wiring before purchase. The available H1 description does not give a numerical maximum screen capacity.
Frequently Asked Questions
Does the H1 need a computer connected during playback?
After content is loaded, the described system supports playback without a continuously connected computer.
How much storage does this H1 controller have?
The product information lists 32 GB of eMMC storage.
Is this page only for a 4G version?
No. The product options include H1 with a 3G module and H1 with a 4G module. Choose the required configuration.
What content can the H1 display?
Video, images and text are listed as supported program content.
Does the H1 system use receiving boards?
Yes. The described arrangement uses one main board and receiving boards. Confirm the compatible receiving boards and screen layout for your installation.
