Sysolution D70-16 Standard LED Receiving Card
The D70-16 is a standard receiving card for LED cabinets using HUB75E module connections. It provides 16 interfaces and up to 32 RGB parallel data groups. An MCU-based design and online hardware reset support help with configuration and maintenance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Module outputs | 16 × HUB75E |
| RGB data | 32 parallel groups |
| Maximum / brightness-corrected load | 512 × 256 pixels |
| Chromaticity-corrected load | 512 × 160 pixels |
| Scan range | 1–64 |
| Cascaded cards | Fewer than 200 |
| Input voltage | DC 3.5–5.5 V |
| Rated current / power | 0.6 A / 3 W |
| Operating temperature | −20°C to +75°C |
| Operating humidity | 10%–90% RH |
| Board dimensions | 144.02 × 91.19 mm |
| Net weight | 106.7 g |
| Configuration software | LedSet3.0 |
Replacing a Cabinet Receiving Card
Check the module driver, connector pin assignment and cabinet scan settings before replacement. Retain the working configuration and verify the complete cabinet image after installation. A matching connector count alone is insufficient to establish compatibility.
Frequently Asked Questions
How many HUB75E ports does the D70-16 have?
It has 16 HUB75E ports and supports 32 RGB parallel data groups.
What is the maximum load?
The listed maximum is 512 × 256 pixels. Chromaticity correction uses the separate 512 × 160 limit.
Can I recover existing receiving-card parameters?
Parameter readback is supported through LedSet3.0.
Does the D70-16 support network-cable backup?
Yes. The datasheet describes network loop backup using main and standby cable paths.
What power input is specified?
The card accepts DC 3.5–5.5 V. Its rated current is 0.6 A and rated power is 3 W.
