Features of VDwall LVP606A HD LED Video Processor with 4 VGA Inputs:
1. 10+ Bit Faroudja® DCDI Cinema Processing
2. New Faroudja® Real Color®
3. Advanced 4×4 Pixels Interpolation Scaling Algorithm
4. 4-channel VGA input interface
5. Pre-switch, seamless switch,fade-in / fade-out functions between 2 random input signals
6. Dual PIP display( PIP ) ， Unrestricted tri-picture display
7. Independent H & V Scaling Ratios
8. HDMI 1.3a with HDCP, HD 1080p input
9. 1920 x 1080 p or 1600 x 1200 output for single machine
10. Easy setup and adjustment through keys on the panel
11. Press keys on frontal panel to directly select 7-channel input signal source, including:
2 x VGA 1 x DVI / HDMI( with HDCP )
2 x DVI-I ( VGA / DVI / HDMI with HDCP ) 2 x CVBS
12. 2 channels can be configured to connect external stereo audio, plus HDMI audio,
there are 3-channel audio for synchronous switch
13. 2 LED Transmission Cards Built-in ability （The processor does not include the Transmission card)
Download Specification:
