Sysolution E60B-DC Networked LED Controller
The E60B-DC combines local content editing with cloud-based remote cluster control. Onboard Wi-Fi works in AP or Station mode, and the built-in web server supports program editing from computers, phones and tablets. LedOK Express is the listed companion software.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | E60B-DC |
| Listed LED resolution | 1280 × 720 pixels |
| Video decoding | 1080p hardware decoding |
| Connectivity | Ethernet, 4G, Wi-Fi and USB drive |
| CPU | Quad-core A7, 32-bit, 1.1 GHz |
| GPU | A307, 409.6 MHz |
| Memory / storage | 1 GB LPDDR3 / 8 GB eMMC |
| Operating system | Android 5.1 |
| Wi-Fi | IEEE 802.11b/g/n, 2.4 GHz |
| Bluetooth | BT 4.1 |
| Satellite positioning | GNSS GPS / BeiDou / GLONASS |
| Module scan support | Full-color static through 1/32 scan |
| Audio / USB camera | Supported |
| Weather forecast / content readback | Supported |
| Software | LedOK Express |
| Secondary development | Supported |
Regional 4G Selection
The original product data distinguishes China, North America, Eurasia and Latin America cellular configurations. Select the actual modem version for the country and operator; these regional entries do not mean a single unit supports every listed network band. Confirm the module included with the order.
Video and LED Output
1080p describes hardware video decoding. The LED display resolution is listed separately as 1280 × 720. Check the receiving hardware, driver chip and scan configuration when planning the display.
Frequently Asked Questions
What software is used with E60B-DC?
LedOK Express is listed for this controller. The built-in web server also supports local program editing.
Does E60B-DC support Wi-Fi hotspot mode?
Yes. Its onboard Wi-Fi supports both AP and Station modes.
What is the difference between 1080p decoding and its LED resolution?
1080p refers to decoding the source video. The product lists a separate 1280 × 720 LED resolution.
Will its 4G connection work in every country?
The modem configuration is region-dependent. Confirm the supplied version against the installation country and network operator.
Can it connect to a USB camera?
USB-camera support is listed. Confirm the particular camera and software requirements for the intended application.
