Function of HUB75B LED Wall HUB Card:
Transfer the signal from LED receiving card to LED modules, such as the traditional indoor LED modules, P10, P7.62, P6, P5, P4, P3 and P2.5.
Interface Definition of HUB75B LED Wall HUB Card:
1 |
R1 |
2 |
G1 |
3 |
B1 |
4 |
GND |
5 |
R2 |
6 |
G2 |
7 |
B2 |
8 |
GND |
9 |
A |
10 |
B |
11 |
C |
12 |
D |
13 |
CLK |
14 |
STB |
15 |
OE |
16 |
GND |
