CP2048 control panel for live video switching
The RGBlink CP2048 gives an operator direct access to source selection and transition controls for Program and Preview. Its rotary controls, selection buttons and T-bar support adjustments during LED display presentations. The connected video processor determines the available signal connections and screen-processing capabilities.
Control interfaces and physical specifications
| Parameter | Specification |
|---|---|
| Serial control | RS232; 9-pin female D connector |
| Ethernet control | 1 × RJ45 female |
| Ethernet data rate | 10/100 Base-T; half/full duplex with auto-detection |
| Ethernet protocol | UDP |
| Operator controls | Program/Preview input selection; picture controls; transition selection; rotary control; T-bar |
| Power specification on original product page | 100–240 VAC, 50/60 Hz; 2 × 25 W; internal redundant dual power supply |
| Power range in linked quick-start guide | 85–264 VAC, 50/60 Hz; confirm the unit nameplate where these published ranges differ |
| Operating temperature / humidity | 0–50°C / 10–90%, non-condensing |
| Storage temperature / humidity | −40–70°C / 10–90%, non-condensing |
| Enclosure | Metal; 480 × 330 × 130 mm |
| Product weight | 6.5 kg |
System compatibility
The linked quick-start guide describes CP2048 V1.4 control of VSP729, VSP3600 and VSP5360 switchers, including a VSP5360 setup example. Verify the installed software and processor model before assuming compatibility with another VSP unit.
Frequently asked questions
Is the CP2048 a standalone video processor?
It is a control panel for compatible video switchers. Source connections and video processing belong to the connected switcher; confirm that device when planning the signal path.
What is the T-bar used for?
The T-bar provides manual transition control between Preview and Program. Transition selection and picture controls are available on the panel.
How does the CP2048 connect for control?
The original specification lists RS232 and an RJ45 Ethernet control port, using 10/100 Base-T and UDP. Match the control settings to the connected processor.
Which VSP switchers are documented with CP2048?
The quick-start guide names VSP729, VSP3600 and VSP5360 for CP2048 V1.4. Confirm your model and software version before purchase.
