LISTEN V9BOX LED Display Full-color sync control system Parameter:
parameters | |
| Type | Full-color sync control system |
| Scan | Support Static to 1/32 scan, compatible with mainstream driver IC |
| Control Range | Double net output ports, user-defined width and height ( the highest & widest can be 2048 pixels); |
| output resolution up to 1.3 million pixels under 60HZ ; | |
| output resolution up to 2.0 million pixels under 30HZ; | |
| Supply Voltage | 5V |
| Control Mode | USB interface control |
| Video Interface | DVI |
| Audio Interface | 3.5mm |
| Output Interface | Double net ports |
| Cascade Interface | RJ11（out & in） |
| Auxiliary Receiving Card | V301 Series |
| Working Temperature | -40℃- 85℃ |
| Software | LED SyncPlayer |
Downloda Specification of LISTEN V9BOX LED Display Full-color sync control system:
