Offline Video Playback for LED Displays
The Lumen C-Power6200 is an asynchronous LED video controller with DDR3 RAM and audio output. It supports full-color video programs and updates through TCP/IP, USB flash drive or serial communication. Memory options are 256 MBytes, 4 GBytes and 8 GBytes; select the required option when ordering.
Control Size and Scan-Board Requirements
The maximum control size is 640 × 480 pixels with scan boards. Without a scan board, the published limit for a single main board is a maximum output height of 256 pixels. These are different configurations; check the scan-board arrangement before sizing the LED display.
Technical Specifications
| Parameter | Specification |
|---|---|
| Controller type | Asynchronous / offline LED video controller |
| Control size with scan boards | Maximum 640 × 480 pixels |
| Single main board without scan board | Maximum output height: 256 pixels |
| Grayscale | 256–64K levels |
| RAM type | DDR3 |
| Memory options | 256 MBytes, 4 GBytes or 8 GBytes |
| Font library space | 128 MB |
| Program capacity | Up to 512 programs |
| Playback windows | Up to 10 per program |
| Video formats named in the listing | MP4 and AVI; verify file requirements before use |
| Other content | SWF/GIF animation, pictures, text, clocks and temperature information |
| Audio | Audio output |
| Network interface | TCP/IP, 10M/100M adaptive |
| USB | Program updates by USB flash drive |
| Serial communication | RS232/RS485; maximum baud rate 115200 |
| Software | LedCenter V5.2.0 or above |
| Effects | More than 60 text and picture effects |
| Clock and sensors | Real-time clock; digital/analogue clocks; external sensors with 32-grade brightness support |
| Remote operation | Program-list editing and display control by infrared controller or keyboard |
Program Layout and Integration
Separate playback windows can display different content formats. Transparent text and clocks can overlay photos or video, while scheduled playback supports week, hour and minute settings. Programs can be organized hierarchically for maintenance.
Multilingual font libraries include English, simplified and traditional Chinese, Japanese and Korean, with font-library editing and update tools. An intelligent setting tool is listed for LED module configuration; confirm the interface and scan requirements of your particular modules.
External communication components can provide GPRS/CDMA, ZigBee or RF communication. These are listed separately from the standard TCP/IP, USB and serial interfaces. A custom-development interface, documentation, demonstration programs and source code are also listed.
Frequently Asked Questions
Can the C-Power6200 play video offline?
Yes. It is an asynchronous video controller for offline LED display programs, with video playback and audio output listed.
Does 640 × 480 apply without scan boards?
No. The 640 × 480 maximum is specified with scan boards. A single main board without a scan board is listed with a maximum output height of 256 pixels.
What memory options can I select?
The available memory choices on this product page are 256 MBytes, 4 GBytes and 8 GBytes. Choose the intended capacity in the product options before adding it to the cart.
How are display programs updated?
The listed interfaces are 10M/100M adaptive TCP/IP, USB flash-drive updating and RS232/RS485 serial communication with a maximum baud rate of 115200.
Which software and video formats are listed?
The software requirement is LedCenter V5.2.0 or above. MP4 and AVI are named among the video formats. Confirm encoding and file requirements for the selected hardware and software before preparing a full playlist.
Need help checking scan boards or memory selection? Send us your screen and controller details.
