Magnimage 500A LED Display Video Processor Feature:
- Image crop
- Image freeze
- Template setting
- Seamless scaler
- DVI enhancement
- Part/Full
Magnimage 500A LED Display Video Processor Specification
Inputs
Ports | No. | Resolution Specification |
AV | 1 | PAL NTSC SECAM |
VGA | 1 | VESA |
DVI | 1 | VESA |
HDMI | 1 | HDMI 1.3 |
Outputs
Ports | No. | Resolution Specification |
DVI | 1 | 1024×768/60Hz/75Hz/85Hz/100Hz/120Hz 1280×1024/60Hz 1440×900/60Hz 1600×1200/60Hz 1600×1200/60Hz-Reduced 1680×1050/60Hz 1920×1080/60Hz 2560×816/60Hz 1920×1200/60Hz 2048×1152/60Hz 1024×1280/60Hz 1536×1536/60Hz |
Console specification
Power supply | 100~240 AC 50/60Hz |
Power consumption | 20W |
Operation temperature | 0~45℃ |
Product dimension(L×W×H) | 253.0×176.2×44.5mm(LED-500A) 482.0×240.5×44.5mm(LED-500B) |
Packing dimension(L×W×H) | 383.0×240.0×100.0mm(LED-500A) 555.0×395.0×125.0mm(LED-500B) |
N.W. | 1.6kg(LED-500A) |
G.W. | 2.4kg(LED-500A) |
Download:
Magnimage 500A LED Display Video Processor Specification Download
