Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply

$38.50

Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply

SKU: Meanwell-HSP-300-5 Category: Brand:

Availability: 6709 in stock

Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply Features:

  1. Universal AC input / Full range
  2. Withstand 300VAC surge input for 5 seconds
  3. Built-in active PFC function
  4. Low leakage current<1mA
  5. Protections: Short circuit / Overload / Over voltage / Over temperature
  6. Cooling by free air convection
  7. Low profile:31mm
  8. Conformal coated
  9. LED indicator for power on
  10. Suitable for high efficiency moving sign applications
  11. 3 years warranty



Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply Parameter:

MODEL HSP-300-5
OUTPUT DC VOLTAGE 5V
RATED CURRENT 60A
CURRENT RANGE 0 ~ 60A
RATED POWER 300W
RIPPLE & NOISE (max.) Note.2 150mVp-p
VOLTAGE ADJ. RANGE 4.5~5.5V
VOLTAGE TOLERANCE Note.3 ±2.0%
LINE REGULATION Note.4 ±0.5%
LOAD REGULATION Note.5 ±1.0%
SETUP, RISE TIME 2000ms, 100ms/230VAC
3000ms, 100ms/115VAC at full load
HOLD UP TIME (Typ.) 8ms/230VAC         8ms/115VAC at full load
INPUT VOLTAGE RANGE 180 ~ 264VAC     254 ~ 370VDC
or 90~135VAC    127~190VDC
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR (Typ.) PF0.93/230VAC
PF 0.98/115VAC at full load
EFFICIENCY (Typ.) 87%
AC CURRENT (Typ.) 4.7A/115VAC        2.35A/230VAC
INRUSH CURRENT (Typ.) Cold start 30A/115VAC 60A/230VAC
LEAKAGE CURRENT <1mA / 240VAC
PROTECTION OVER LOAD 105~150% rated output power
Protection type : Hiccup mode,
recovers automatically after fault
condition is removed
5.7 ~ 7.0V
OVER VOLTAGE Protection type : Shut down o/p voltage,
re-power on to recover
OVER TEMPERATURE Shut down o/p voltage, recovers automatically
after fault condition is removed
ENVIRONMENT WORKING TEMP. -30 ~ +70℃(Refer to “Derating Curve”)
WORKING HUMIDITY 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +85℃, 10 ~ 95% RH
TEMP. COEFFICIENT ±0.03%/℃ (0 ~ 60℃)
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, 60min.
each along X, Y, Z axes
SAFETY& EMC SAFETY STANDARDS UL60950-1,EN60950-1,CCC GB4943 approved
WITHSTAND VOLTAGE I/P-O/P:3.0KVAC    I/P-FG:2.0KVAC
O/P-FG:0.5KVAC
ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:
100M
 Ohms/500VDC/25/ 70%RH
EMC EMISSION Compliance to EN55022 (CISPR22),GB9254,
Class
 B, EN61000-3-2,-3,
GB17625.1
EMC IMMUNITY Compliance to EN61000-4-2,3,4,5,6,8,11;
EN55024,
 light industry level
(surge 4KV), criteria A
OTHERS MTBF 263.2K hrs min.     MIL-HDBK-217F (25℃)
DIMENSION 210*81*31mm (L*W*H)
PACKING 0.8kg; 15pcs/ 12.1kg/ 0.7CUFT

Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply

Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply

Download Specification:

Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply Specification

Will I be charged with customs and taxes?

The prices displayed on our site are tax-free in US Dollars, which means you may be liable to pay for duties and taxes once you receive your order. Import taxes, duties and related customs fees may be charged once your order arrives to its final destination, which are determined by your local customs office. Payment of these charges and taxes are your responsibility and will not be covered by us. We are not responsible for delays caused by the customs department in your country. For further details of charges, please contact your local customs office.

Weight 0.85 kg
