NovaStar PCC80 asynchronous LED display card
The NovaStar PCC80 is a full-color asynchronous LED display control card with a maximum resolution of 640 × 128 pixels. It supports video, images, text and information displays such as clocks and countdowns. The card works with compatible full-color LED modules from static drive to 1/32 scan.
For a replacement card or a new LED sign, check the screen resolution, scan mode and driver IC before ordering. Ethernet cable cascading is not supported, so do not select the PCC80 for an installation that requires cascaded cards.
Key features
- Full-color LED display control for screens up to 640 × 128 pixels.
- Support for video, pictures, text, weather, clocks, countdowns and document content.
- Configurable grayscale up to 65,536 levels and 256 PWM brightness adjustment levels.
- Automatic brightness adjustment and integrated audio output.
- Open- and short-circuit detection with the compatible driver ICs listed below.
PCC80 technical specifications
| Parameter | Specification |
|---|---|
| Brand / model | NovaStar PCC80 |
| Controller type | Full-color asynchronous LED display card |
| Maximum resolution | 640 × 128 pixels |
| Supported LED displays | Full-color, real-pixel displays; static drive to 1/32 scan |
| Ethernet cable cascading | Not supported |
| Content types | Video, pictures, text, weather, clock, countdown, Word, Excel and TXT |
| Video formats | MPEG4, H.264, VC1 and MPEG1 |
| Grayscale | Up to 65,536 levels, configurable |
| Maximum refresh rate | 6,000 Hz for static LED displays; 3,840 Hz for scanning LED displays |
| PWM brightness adjustment | 256 levels |
| Automatic brightness adjustment | Supported |
| Integrated power switch management | 1 |
| LED status detection | Open- and short-circuit checking with MBI5034, MBI5036, MBI5039, MBI5040 or DM13H |
| Brightness loss for calibration | 5%–8% |
| Integrated audio output | Supported |
| Working temperature | −20°C to 80°C |
| Power supply voltage | 4 V–5 V |
Maximum refresh rate and grayscale figures depend on the LED module and configuration; confirm the settings required for your screen before installation.
Supported driver ICs
The listed driver ICs include MBI5041/5042/5045, MY9262, MY9221, MBI505X, MBI515X, MY9266/9268/9269, SUM2030, TLC59282/59283, MY9868, SUM2016/2017 and MBI5020/5024/5034/5035. Check your module’s exact driver IC and scan mode when confirming compatibility.
Before ordering
- Confirm the full screen’s pixel width and height against the 640 × 128 maximum resolution.
- Check the LED module driver IC, scan mode, wiring and power requirements.
- For a replacement, provide a photo of the existing card and LED module labels so the configuration can be checked.
- Confirm the required software and content workflow for your installation before purchase.
Contact us for PCC80 compatibility assistance, or browse our asynchronous LED control cards for other screen requirements.
Frequently asked questions
What is the maximum resolution of the NovaStar PCC80?
The PCC80 supports a maximum resolution of 640 × 128 pixels. Check both the width and height of your screen before selecting the card.
Does the PCC80 support Ethernet cable cascading?
No. Ethernet cable cascading is not supported on this model.
Which LED scan modes are supported?
The card supports compatible full-color, real-pixel LED displays from static drive to 1/32 scan. Driver IC and module wiring must also be checked.
Can the PCC80 display video and output audio?
Yes. The listed video formats include MPEG4, H.264, VC1 and MPEG1, and integrated audio output is supported. Confirm the media settings for your installation.
