K13 Asynchronous Sending Card for Cascaded Displays
The XIXUN K13 supports stored multimedia playback and cascaded LED screen connections. One sending card can serve multiple screens of the same size showing the same content at the same time. PC software is used for configuration.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model / type | K13 / asynchronous cascading sending card |
| Pixel capacity — confirmation required | Feature text: 640 × 128 fixed pixels; parameter table: maximum 2400 × 128. The original listing does not explain the difference. |
| HUB arrangement | One HUB per sending card and one HUB per receiving card |
| Display type | Full color |
| Onboard flash | 500 MB |
| Storage expansion | USB |
| Grayscale | 4,096 levels |
| Scan support | Scan types 1 through 16 |
| Communication ports | Ethernet, serial and USB |
| Audio | Optional USB sound card |
| PWM driver IC example | MBI5041 supported |
| Software | LEDEditor_V10 / LEDSet2.0 |
| Program readback | HCP4 file readback supported |
| Sensor functions | Temperature, humidity, automatic brightness and infrared program switching listed |
Playback and Configuration
Listed media formats include AVI, WMV, MPG, MOV, DAT, VOB, MP4 and FLV video; GIF/SWF animation; BMP/JPG/GIF/WMF/ICO images; and TXT/RTF text. Programs can include tables, analog or digital clocks, timing and countdowns. Scheduled operation is supported.
The listing describes exchanging receiving cards within a screen without repeating setup. Confirm the receiver configuration and screen arrangement before applying that feature. Do not design a screen around either pixel-capacity figure until the exact K13 configuration is verified.
Frequently Asked Questions
What is the maximum display size of K13?
The feature list says 640 × 128 fixed pixels, while the parameter table says 2400 × 128. The source does not reconcile them; confirm the actual card and cascade configuration.
Can one K13 show identical content on several screens?
Yes. The listing specifies multiple screens of the same size displaying the same content at the same time.
Which scan types does K13 support?
The original specification lists scan types from 1 through 16 and gives MBI5041 as an example of a supported PWM driver IC.
How much storage does the K13 have?
The listing specifies 500 MB onboard flash and USB storage expansion.
Which software is listed for the K13?
LEDEditor_V10 and LEDSet2.0 are named. Confirm the compatible software and firmware versions for the installed card.
