M50 Standalone LED Sending Box
The Sysolution M50 manages full-color LED displays over a local network or WiFi. Its built-in web server supports local programming from compatible iOS, Android, Windows and Linux devices. The listed functions include media management, log statistics, redundant backup and irregular-screen configuration.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | M50 |
| CPU | ARM Cortex-A7 dual-core, 1.2 GHz |
| GPU | ARM Mali400MP2 |
| Memory | 1 GB |
| Flash storage | 8 GB |
| LED outputs | 2 |
| Network options | LAN and WiFi |
| AIPS cloud platform | Not supported |
| Display capacity | 1920 × 1080 |
| Display type | Full color |
| Grayscale levels | 65,536 |
| Local programming | Built-in web server |
| Software | Easyboard |
| Screen configuration | LedSyncSet2.0 |
| Receiving card listed | D90 |
| Additional listed functions | Redundant backup, brightness sensor support and irregular-screen support |
Choosing a Local Control System
This listing is for the M50 standalone version. Its network connectivity supports local use, while the specifications explicitly exclude AIPS cloud support. Confirm the module, receiving card and software configuration for the intended screen; no HDMI input or electrical ratings are established by the M50 information on this page.
Frequently Asked Questions
Does the M50 support the AIPS cloud platform?
No. The original M50 specification table explicitly lists AIPS platform support as unavailable.
Can the M50 be configured through WiFi?
Yes. WiFi, LAN and a built-in web server for local programming are listed.
What memory and storage does it have?
The product listing specifies 1 GB memory and 8 GB flash storage.
What display capacity and receiver are listed?
The listed display capacity is 1920 × 1080, and D90 is the named receiving-card type. Confirm the mapping and module setup for your screen.
Is the linked PDF an M50 datasheet?
No. The existing download opens an MA1 document. It is retained below and clearly identified; do not use it to establish M50 electrical or mechanical specifications.
Existing PDF Download
The original download is an MA1 datasheet, not an M50 datasheet. The link is preserved for reference, but its parameters have not been assigned to the M50.
