Notice before order:
1) Parts included: waterproof steel cabinet, LED modules, power supplies, NOVASTAR receiving card, power cables and signal cables. It does not include sending card. You can order the sending card by this link: NOVASTAR MSD300 sending card.
2) Buy cabinets of same batch: to avoid brightness&color difference on one single screen, you must buy cabinets of the same batch. That is, you must buy the cabinets for one single screen by one order from us.
3) Shipping: The above price does not include shipping cost. The goods can be shipped by sea, by air, by train or by express. You can get your forwarder to ship the goods for you. If you need us to ship the goods, please talk with our online sales to confirm the shipping details.
4) Tarrif: Our price does not include any tarrif or duties at the destination, you should do import customs clearance and pay all tarrif or duties locally.
Features of P3.91 Outdoor Front Service Rental LED Panel:
1)Magnetic front service, easy to assemble and disassemble the modules from front side.
2) Slim cabinet, only 90mm thick.
3) Light weight, only 7KG for 500x500mm cabinet.
4) Non-gaps between cabinets, due to accurate-made die-cast Magnesium cabinet.
5) Fast lock design, good rental hanging solution.
Applications of P3.91Outdoor Front Service Rental LED Panel:
Outdoor rental LED panel
Outdoor fixed installation LED panel requires front service
Parameters of P3.91 Outdoor Front Service Rental LED Panel:
|
Item |
Parameter |
|
|
Pixel Pitch |
3.91mm |
|
|
Cabinet Material |
Die-cast Magnesium alloy |
|
|
Color |
Black |
|
|
Cabinet Size |
500*500 mm |
|
|
Cabinet Resolution |
128*128 pixels |
|
|
Module quantity |
2*2 |
|
|
Density |
65536pixels/㎡ |
|
|
Whitebalance brightness |
≥5500CD/㎡ |
|
|
Color temperature |
6500K——8000K |
|
|
Viewing angle |
H:120;V:120 |
|
|
Protection grade |
Front/Rear:IP31/IP31 |
|
|
Non-Flatness |
＜0.2mm |
|
|
Module interval |
＜0.2mm |
|
|
Cabinet Weight |
7.5kg/Cabinet |
|
|
Packaging Gross Weight(KG) |
60kg(Estimated data) |
|
|
Packaging dimension |
750*570*660mm(6cabinet in one case) |
|
|
Maximal power/㎡ |
700W/㎡ |
|
|
Average power/㎡ |
300W/㎡ |
|
|
Frame frequency |
≥60Hz |
|
|
Refresh frequency |
1920Hz |
|
|
Gray grade |
13bit |
|
|
Brightness adjusted |
256 grade by auto-optic/color &8 grade by hand |
|
|
Input signal |
RF,S-video,RGB,RGBHV,YUV,YC&Composition,etc |
|
|
Control system |
Novastar / Linsn / Colorlight |
|
|
System supports |
WindowsXP,WIN 7 |
|
|
MTBF |
>5000h |
|
|
Life-span |
>100000h |
|
|
Speckles rate
|
<0.0002 |
P3.91 Indoor 500X500mm Rental LED Screen Board:
The EA500C3 Series is made of sturdy and beautiful materials,and there are two quick locking devices on the left and right sides, which can ensure faster assembly speed and better screen flatness.It also has bumper feet on the bottom of the cabinet to protect the edges of the LED modules.
EA500C3 Series LED sign has four corner protectors in each corner to prevent LED to be damaged,
more security for transport, installation, operation, assemble & disassemble foldable design, and easy to use.
EA500C3 series supports design of LED display with front side service.The magnet LED module can be disassembled and maintained by front-end tools,
which is simple and convenient, saving your cost and labor.
EA500C3 indoor rental LED display front service series, power box hollow design,easy maintenance, excellent heat dissipation.
P3.91 Indoor Rental LED Screen Panel 500X500mm Application Scenario：
Download Specification:
