Notice before order:
1) Parts included: waterproof steel cabinet, LED modules, power supplies, NOVASTAR receiving card, power cables and signal cables. It does not include sending card. You can order the sending card by this link: NOVASTAR MSD300 sending card.
2) Buy cabinets of same batch: to avoid brightness&color difference on one single screen, you must buy cabinets of the same batch. That is, you must buy the cabinets for one single screen by one order from us.
3) Shipping: The above price does not include shipping cost. The goods can be shipped by sea, by air, by train or by express. You can get your forwarder to ship the goods for you. If you need us to ship the goods, please talk with our online sales to confirm the shipping details.
4) Tariff: Our price does not include any tariff or duties at the destination, you should do import customs clearance and pay all tariff or duties locally.
P3.91 Outdoor High Definition Rental LED Display
P3.91 Outdoor High Definition Rental LED Display Features:
1) Outdoor ultra high definition LED Display at 62,500pixel/sqm.
2) High quality SMD1921 LEDs are used which is long life span, reliable quality.
3) High luminance and low Brightness attenuation.
4) High refresh rate and color depth as well as 120degree viewing angle both for horizontal and vertical.
P3.91 Outdoor High Definition Rental LED Display Parameters:
| LED Module | ||
| Resolution | 64(H)×64(V) | |
| Pitch | 3.91mm | |
| Density | 65,410 pixels/㎡ | |
| LED Type | SMD1921 | |
| Driver Mode | Dynamic 1/16 Duty constant current | |
| Size | 250 mm×250 mm | |
| Mask | Pure Black mask-high contrast screen | |
| LED Panel | ||
| Resolution | 128(H)×128(V) | |
| Size | 500mm× 500mm | |
| Weight | 9KG | |
| Operation Power | AC100-240V 50-60HZ Switch-able | |
| Maxim Power Consumption | 1000 W/m2 | |
| Average Power Consumption | 500 W/m2 | |
| Electricity Parameter | ||
| Optical Ratings | ||
| Brightness | ≥6000cd/㎡ | |
| View Angle | 140 degree ( horizontal) 140degree(vertical) | |
| View Distance | 4m-60m | |
| Gray Scale | 8bits input, correction with 14bits | |
| Display Color | 549.7G | |
| Brightness Adjustment | 100 levels | |
| Control System | ||
| Correction Scale Level | 16bits | |
| Frame Update Frequency | 60Hz | |
| Screen Refresh Frequency | 960Hz | |
| Gamma Correction | -5.0—5.0 | |
| Support Input | Composite Video, S-Video, DVI, HDMI., SDI, HD_SDI | |
| Control Distance | Ethernet cable 100m, optical fiber 5km | |
| Support VGA Mode | 800×600,1024×768,1280×1024,1600×1200 | |
| Color Temperature | 5000-9300 adjustable | |
| Brightness Correction | dot by dot, module by module, cabinet by cabinet | |
| Reliability | ||
| Operating Temp. | -20-60 Celsius degree | |
| Operating Humidity | 10-95% RH | |
| Operating Life | 100,000 hours | |
| MTBF | 5000 hours | |
| Continuous Working Time | ≥48 hours | |
| Protection Level | IP65(Front),IP54(Rear) | |
| Out of Control Pixel Rate | 0.01% | |
Download:
P3.91 Outdoor High Definition Rental LED Display Specification
