Features of VDWALL LVP603S HD LED Video Switcher:
1. 10+ Bit Faroudja® DCDI Cinema Processing
2. New Faroudja® Real Color®
3. Advanced 4×4 Pixels Interpolation Scaling Algorithm
4. HD Text, Flash, Graphics & Logo Overlay
5. Seamless Switching,Fade-in / Fade-out
6. Unrestricted HD Picture-in-Picture (PIP) & Picture-by-Picture
7. Independent H & V Scaling Ratios
8. HDMI 1.3a with HDCP, HD 1080p input
9. SDI. HDSDI(1080i) Input
10. 1920 x 1080 p or 1600 x 1200 output for single machine
11. Multi-machine in parallel, 6 x 6 in parallel can connect 11520 x 6480 LED screen
12. Fast 64-level output brightness adjustment
13. Easy setup and adjustment through keys on the panel
14. Press keys on frontal panel to directly select 7-channel input signal source, including:
1 x SDI/HDSDI 1 x HDMI(with HDCP) 1 x DVI
1 x VGA 1 x DP(DisplayPort) 2 x CVBS
15. 2 channels can be configured to connect external stereo audio, plus DP, HDMI and SDI audio,
there are 5-channel audio for synchronous switch
16. 2 LED Transmission Cards Built-in ability （The processor does not include the Transmission card.）
Terms&Conditions of VDWALL LVP603S HD LED Video Switcher:
Delivery time: within 8 working days upon receiving payment..
Payment method: Paypal and credit card are preferred.
Packaging strong cardboard carton.
Warranty: two years.
Shipping method: DHL express is the default method. Others like EMS, UPS, FedEX and TNT will be adopted only when DHL is not available or not suitable at the destination; If you would like to ship the goods by sea or by air, please contact us for details
Remark : Full technical support will be provided only when you order both LED modules(LED display) and controller system from our company.
