The H-01 uses an adjustable suction head to lift a removable LED module from the front. Its replaceable battery and automatic power-off are useful when servicing several screens at one site.
Selection and setup
Match the suction opening to the available module face. The published continuous-discharge figure is a laboratory result; battery condition and the working environment can change actual operating time.
Technical specifications
| Parameter | Specification |
|---|---|
| Battery energy | 43.2 Wh |
| Charger input | 100–240 V |
| Charger output | 25.2 V |
| Listed charge time | 2 hours |
| Continuous discharge | 18–20 minutes under laboratory conditions |
| Working environment | −20 to 45 °C, 15–85% RH |
Product images and resources





EagerLED H-01 LED Display Front Maintenance Tool
Frequently asked questions
1. Can the H-01 battery be replaced?
Yes. The H-01 supports battery replacement, which is useful when the tool is used across several cabinets.
2. How long does it run on one charge?
The published laboratory result is 18–20 minutes of continuous discharge. Actual service time depends on the conditions.
3. Will the head fit more than one module size?
The suction opening is adjustable. Check the face area and cabinet service instructions before choosing the setting.
